ARC Audio KS 2500.1

ARC Audio KS 2500.1
mono zosilňovač

• Ultra high power subwoofer amplifier design
• High capacity copper core PCB design
• Advanced microprocessor control system
• Non digital Class H switching design
• Dedicated hand wound output inductors
• Flashable Microprocessor technology monitors all aspects of the amplifiers performance increasing stability and long term performance
• Code based flashing diagnostics
• Protection against: reverse voltage, Over voltage, Speaker short, and Thermal Overload
• Very high dampening factor
• Can drive highly reactive load
• Optically isolated mosfet power supply
• Hi/Low Level switchblade RCA inputs for flexible integration into most OEM/Aftermarket applications
• Quiet internal forced induction cooling fan
• 1 Channels @ 4 Ohms: 750 Watts
• 1 Channels @ 2 ohms: 1400 Watts
• 1 Channel @ 1 Ohms: 2500 Watts
• Frequency Response: 20Hz - 250kHz
• Crossover Range: 30Hz - 250Hz
• Bass Boost: +15dB @ 45Hz
• S/N Ratio: 103dB
• Input Sensitivity (Low): 200mV - 3.5V
• Max Current Draw: 210A @ 2600 Watts 2% THD
• Fuse: No Onboard Fuses (External Fuses Recommended)
• Idle Current: 1.14 Amp
• Dimensions: 21.5"(L) x 8.0"(W) x 2.325"(H)
